BCD436HP/BCD536HP: Attenuator

Status
Not open for further replies.

JethrowJohnson

I love P25
Joined
Sep 10, 2022
Messages
939
Location
Marietta OH
What is attenuation supposed to do when you turn it on for a channel, and will it make the sound any louder? I already have the offset on this channel set to +3 but it's still hard to hear sometimes especially if the officer isn't speaking directly into the microphone. Thanks 🙂

Joined
Apr 18, 2009
Messages
6,363
Location
CT
What is attenuation supposed to do when you turn it on
Attenuation lessens the signal strength.

It doesn't affect audio.

That's volume offset.

Attenuation



JethrowJohnson

I love P25
Joined
Sep 10, 2022
Messages
939
Location
Marietta OH
Attenuation lessens the signal strength.

It doesn't affect audio.

That's volume offset.

Attenuation

Okay. Thank you, I guess that's the opposite of what I need then. And it's just that one channel though, and it's not a problem all the time, but if there's a lot of background noise then I can't hear it over anything, and some of the officers never actually speak into the microphone, they just hold it maybe about halfway or something and then it makes it even harder to understand them. This is with master volume set to 13 and the volume offset on +3. It's okay though. Thanks for the help. 🙂 Goodnight.


Ubbe

Member
Joined
Sep 8, 2006
Messages
9,887
Location
Stockholm, Sweden
This is with master volume set to 13 and the volume offset on +3.
Remember that offset can only use the normal volume steps, so your volume 13 plus 3 will be 15 as that are the max volume you can set on a 436, a 13% difference. When you use lower volume settings a volume 6 will be increased 3 step, a 50% difference. When you try and reduce the volume and set it to 1 it will be increased to volume 4, a 400% difference.

What Uniden should do are to make the volume offset more logical and use a percentage so that it uses less steps at lower volume settings and larger steps at higher volume settings.

Portable scanners doesn't have any powerful speakers or amplifiers so you could use something like a bluetooth speaker to get a more dynamic audio that doesn't overloads at higher levels. Or if used in a car there are often an aux input to the cars audio system with a standard 3,5mm plug, the same as on the scanner, but then you cannot listen to any background music at the same time. In Europe we have RDS in car radios that interrupts and override any ongoing audio to play important local traffic information updates. Don't know if US has some similar functions or you will miss out on that info. Sometimes a more effective passive external speaker are all it takes. I tried a 2 ohm Motorola speaker and it sounds good, but the overall volume seems to be low on 436 as it doesn't overload at max volume and are lots of headroom left as if volume 20 could be the max setting.

Uniden could raise the gain to the speaker amplifier to at least twice the level to get the volume settings more useable.

/Ubbe


JethrowJohnson

I love P25
Joined
Sep 10, 2022
Messages
939
Location
Marietta OH
Remember that offset can only use the normal volume steps, so your volume 13 plus 3 will be 15 as that are the max volume you can set on a 436, a 13% difference. When you use lower volume settings a volume 6 will be increased 3 step, a 50% difference. When you try and reduce the volume and set it to 1 it will be increased to volume 4, a 400% difference.

What Uniden should do are to make the volume offset more logical and use a percentage so that it uses less steps at lower volume settings and larger steps at higher volume settings.

Portable scanners doesn't have any powerful speakers or amplifiers so you could use something like a bluetooth speaker to get a more dynamic audio that doesn't overloads at higher levels. Or if used in a car there are often an aux input to the cars audio system with a standard 3,5mm plug, the same as on the scanner, but then you cannot listen to any background music at the same time. In Europe we have RDS in car radios that interrupts and override any ongoing audio to play important local traffic information updates. Don't know if US has some similar functions or you will miss out on that info. Sometimes a more effective passive external speaker are all it takes. I tried a 2 ohm Motorola speaker and it sounds good, but the overall volume seems to be low on 436 as it doesn't overload at max volume and are lots of headroom left as if volume 20 could be the max setting.

Uniden could raise the gain to the speaker amplifier to at least twice the level to get the volume settings more useable.

/Ubbe
Thank you. I've actually been thinking of getting a speaker for it.
