Looks like Gainesville is getting a trunked system. ULS License - PubSafty/SpecEmer/PubSaftyNtlPlan,806-817/851-862MHz,Trunked License - WRYI679 - GAINESVILLE, CITY OF
Gainesville TRS
- Thread starter ffighter17
- Start date
Interesting. I wonder what the cost difference is compared to joining the Denton/Cooke Co. system. Here's an article related to it. Gainesville upgrades city public safety communications. It's going to be a Tait system possibly connected to Sherman.
Last edited:
I think I heard a Gainesville PD unit(Radio ID 791####) calling Cooke Co. SO on the Denton/Cooke Co system, so I'm guessing they might have new radios. I'm not hearing their new system from Bedford, and would not expect to. Anyone closer might try tuning in to see if it's up.
Last edited:
- Joined
- Jul 19, 2019
- Messages
- 489
Cooke Co. and Gainesville TRS is part of the Denton Regional Radio system. Seems that was always their sneaky plan from the beginning.
Last thing I read in #2 above, was it was going to be a Tait system connected to Sherman.
- Joined
- Jul 19, 2019
- Messages
- 489
Unless something has changed, Cooke/Gainesville are on Denton County. I can't read that link as they are spamming me to buy a subscription.
Denton County Regional Radio System Trunking System, Denton, Texas
Denton County Regional Radio System Trunking System Profile
www.radioreference.com
- Joined
- Jul 19, 2019
- Messages
- 489
Okay Ben, found a link I could read. Seems like Gainesville is system swapping. However, the article says they are fostering a share option with Sherman who uses the same system. So the article really seems more like Gainesville is reaching out to Sherman more for Interoperability than a shared system. There is a lot of land between Sherman and Gainesville, I can't see it being one big system. But, who buys a Tait system in the first place? I guess we'll see.
www.taitcommunications.com
Gainesville Enhances Public Safety Communications with Tait P25 Radio System |
City of Gainesville, Texas, is taking a significant step forward in enhancing public safety and municipal communications. The Gainesville City Council has approved an important agreement with Tait Dealer, Stolz Telecom for the implementation of a Tait Communications Project 25 Phase 2 Trunked...
Took a Sunday drive up that way, and found a little info.
Only talkgroup I heard was 4911 for Gainesville Police. Didn't catch any fire channels. Just not much going on when I was there. I did not hear any of their conventional channels.
Mobile/Portables in the RIDs 791#### ranges
Dispatch Consoles RID 1000000#
Activity Summary - Decoder 25 Phase 1 Normal (C4FM)
Network
WACN:C0907[788743] SYSTEM:F09[3849] NAC:F09[3849] LRA:01[1]
Current Site
SYSTEM:F09[3849] NAC:F09[3849] RFSS:02[2] SITE:01[1] LRA:01[1] STATUS:ACTIVE RFSS NETWORK CONNECTION
PRI CONTROL CHANNEL:0-243 DOWNLINK:854037500 UPLINK:809037500
SEC CONTROL CHANNEL:0-399 DOWNLINK:855987500 UPLINK:810987500
AVAILABLE SERVICES:[NETWORK_ACTIVE, GROUP_VOICE, INDIVIDUAL_VOICE, PSTN_TO_UNIT_VOICE, UNIT_TO_PSTN_VOICE, INDIVIDUAL_DATA, UNIT_REGISTRATION, GROUP_AFFILIATION, USER_STATUS, USER_MESSAGE, UNIT_STATUS, USER_STATUS_QUERY, UNIT_STATUS_QUERY, UNIT_PAGE, EMERGENCY_ALARM] SUPPORTED SERVICES:[NETWORK_ACTIVE, GROUP_VOICE, INDIVIDUAL_VOICE, PSTN_TO_UNIT_VOICE, UNIT_TO_PSTN_VOICE, INDIVIDUAL_DATA, UNIT_REGISTRATION, GROUP_AFFILIATION, USER_STATUS, USER_MESSAGE, UNIT_STATUS, USER_STATUS_QUERY, UNIT_STATUS_QUERY, UNIT_PAGE, EMERGENCY_ALARM]
Neighbor Sites
UNKNOWN
Frequency Bands
BAND:0 FDMA BASE:851000000 BANDWIDTH:12500 SPACING:12500 TRANSMIT OFFSET:-45000000
BAND:1 FDMA BASE:769000000 BANDWIDTH:12500 SPACING:6250 TRANSMIT OFFSET:30000000
BAND:2 TDMA BASE:851000000 BANDWIDTH:12500 SPACING:12500 TRANSMIT OFFSET:-45000000 TIMESLOTS:2
BAND:3 TDMA BASE:769000000 BANDWIDTH:12500 SPACING:6250 TRANSMIT OFFSET:30000000 TIMESLOTS:2
Only talkgroup I heard was 4911 for Gainesville Police. Didn't catch any fire channels. Just not much going on when I was there. I did not hear any of their conventional channels.
Mobile/Portables in the RIDs 791#### ranges
Dispatch Consoles RID 1000000#
Activity Summary - Decoder 25 Phase 1 Normal (C4FM)
Network
WACN:C0907[788743] SYSTEM:F09[3849] NAC:F09[3849] LRA:01[1]
Current Site
SYSTEM:F09[3849] NAC:F09[3849] RFSS:02[2] SITE:01[1] LRA:01[1] STATUS:ACTIVE RFSS NETWORK CONNECTION
PRI CONTROL CHANNEL:0-243 DOWNLINK:854037500 UPLINK:809037500
SEC CONTROL CHANNEL:0-399 DOWNLINK:855987500 UPLINK:810987500
AVAILABLE SERVICES:[NETWORK_ACTIVE, GROUP_VOICE, INDIVIDUAL_VOICE, PSTN_TO_UNIT_VOICE, UNIT_TO_PSTN_VOICE, INDIVIDUAL_DATA, UNIT_REGISTRATION, GROUP_AFFILIATION, USER_STATUS, USER_MESSAGE, UNIT_STATUS, USER_STATUS_QUERY, UNIT_STATUS_QUERY, UNIT_PAGE, EMERGENCY_ALARM] SUPPORTED SERVICES:[NETWORK_ACTIVE, GROUP_VOICE, INDIVIDUAL_VOICE, PSTN_TO_UNIT_VOICE, UNIT_TO_PSTN_VOICE, INDIVIDUAL_DATA, UNIT_REGISTRATION, GROUP_AFFILIATION, USER_STATUS, USER_MESSAGE, UNIT_STATUS, USER_STATUS_QUERY, UNIT_STATUS_QUERY, UNIT_PAGE, EMERGENCY_ALARM]
Neighbor Sites
UNKNOWN
Frequency Bands
BAND:0 FDMA BASE:851000000 BANDWIDTH:12500 SPACING:12500 TRANSMIT OFFSET:-45000000
BAND:1 FDMA BASE:769000000 BANDWIDTH:12500 SPACING:6250 TRANSMIT OFFSET:30000000
BAND:2 TDMA BASE:851000000 BANDWIDTH:12500 SPACING:12500 TRANSMIT OFFSET:-45000000 TIMESLOTS:2
BAND:3 TDMA BASE:769000000 BANDWIDTH:12500 SPACING:6250 TRANSMIT OFFSET:30000000 TIMESLOTS:2
My turn to take a drive out there, and 4921 appears to be a fire dispatch channel (only heard a tone out and dispatcher notifying station 3 of a "tone test" no live calls).
What I found interesting is the System ID and WACN are the same as Balch Springs in Dallas County (I have picked that system up in my travels and that was logged automatically). The bandplan is identical, and there's no visible overlap in site numbers or in talkgroups, so it's got me curious if these are more than just identical twins (and really is one common system).
What I found interesting is the System ID and WACN are the same as Balch Springs in Dallas County (I have picked that system up in my travels and that was logged automatically). The bandplan is identical, and there's no visible overlap in site numbers or in talkgroups, so it's got me curious if these are more than just identical twins (and really is one common system).
That is interesting, I am hesitant to combine the two in the database since they are so far apart. I'll look and see if I can find any communication about why they are using Balch Springs controller.
nd5y
Member
Gainesville canceled several conventional licenses.
File Number | Call Sign/Lease ID | Applicant Name | FRN | Purpose | Radio Service | Receipt Date | Status |
|---|---|---|---|---|---|---|---|
| 0011242219 | KKD386 | GAINESVILLE, CITY OF | 0009848094 | Cancellation of License | PW | 09/16/2024 | Granted |
| 0011242226 | WPPA242 | GAINESVILLE, CITY OF | 0009848094 | Cancellation of License | PW | 09/16/2024 | Granted |
| 0011242231 | WQCL376 | GAINESVILLE, CITY OF | 0009848094 | Cancellation of License | PW | 09/16/2024 | Granted |
| 0011242237 | WNGT284 | GAINESVILLE, CITY OF | 0009848094 | Cancellation of License | PW | 09/16/2024 | Granted |
| 0011242240 | WNYH454 | GAINESVILLE, CITY OF | 0009848094 | Cancellation of License | PW | 09/16/2024 | Granted |
| 0011242244 | WQCG940 | GAINESVILLE, CITY OF | 0009848094 | Cancellation of License | PW | 09/16/2024 | Granted |
